How I Built Real-Time Hand Tracking in TouchDesigner Using AI (Claude Code + MCP)

بواسطةAli

What You Need

Step 1 — Install Claude Code & the TouchDesigner MCP Server

Claude Code lets AI talk directly to your TouchDesigner project through MCP (Model Context Protocol).

Install the MCP server in one command:

claude mcp add-json touchdesigner –scope user ‘{“command”:”npx”,”args”:[“-y”,”touchdesigner-mcp-server@latest”,”–stdio”]}’

Verify it worked:

claude mcp list

You should see touchdesigner · ✔ connected · 13 tools.

Step 2 — Set Up TouchDesigner

  1. Download touchdesigner-mcp-td.zip from the releases page
  2. Extract it — don’t move any files inside the folder
  3. Open TouchDesigner and drag mcp_webserver_base.tox into your project
  4. Place it at /project1/mcp_webserver_base

The MCP server runs on port 9981 by default.

Step 3 — Install MediaPipe (AI Hand Tracking)

In Claude Code, type:

Install mediapipe in TouchDesigner’s Python environment using a Script DAT, then delete it when done.

Step 4 — Build the Hand Tracking Network

In Claude Code, type:

Create a TouchDesigner network in the current project for real-time hand tracking using the webcam. Use a Video Device In TOP for the webcam, connect it to a Script CHOP using MediaPipe to detect both hands and output 3D positions of thumb tip, index tip, middle tip, ring tip, and pinky tip for each hand. Name channels: left_thumb_tip_x/y/z, right_index_tip_x/y/z etc. Apply lag smoothing. Target 60fps. Put everything inside a Base COMP called hand_tracking.

This creates a complete network with:

  • 30 output channels (5 fingers × 2 hands × 3 axes)
  • Lag CHOP smoothing for stable tracking
  • 60fps webcam input

Step 5 — Build Your Visual

Now the fun part. With hand tracking running, you can build anything on top. Here are three prompts I used:

Hand Skeleton Overlay (like the image above):

Create a Base COMP called hand_skeleton. Show the live webcam feed, draw red dots on each fingertip and green lines connecting the joints for both hands. Draw a white rectangle connecting both index fingertips. Composite over webcam. Output to skeleton_out at 1280×720.

How It Works

Webcam → MediaPipe Script CHOP → Lag Smoothing → hand_out (30 channels)
↓
Your Visual Network

Claude Code sends Python commands to TouchDesigner through the MCP server. It creates nodes, writes scripts, connects wires, and fixes errors — all from a chat interface.
